When it comes to choosing between a pneumatic, electric, and hydraulic tapping arm, the decision depends on several factors, including the specific application requirements, production volume, and budget. Here are some key considerations to help you choose the right tapping arm for your needs. Pneumatic Tapping Arm Pneumatic tapping arms are powered by compressed air
The FlexArm engineering team recently designed a custom solution to counterbalance an Aircat 1994 1″ Superduty Impact Wrench. The tool has a weight of 35 lbs and needs the freedom to rotate about the vertical and horizontal axes, as indicated by the red arrows in figure 1. FlexArm’s solution to this problem was to design
In industrial applications, torque reaction arms play a critical role in maintaining worker safety, improving productivity, and reducing workplace injuries. An end user came to us looking for an ergonomic solution for an Atlas Copco ETV-ST101-370-FS-F Nut Runner. The FlexArm engineering team created a custom torque reaction arm to fit their needs. This custom torque
Flex Machine tools is pleased to announce that Brandon Recker has been named as the company’s new President. With over ten years of experience with the company, Brandon is well equipped to lead Flex Machine Tools into the future and continue to drive its growth and success. Brandon has a strong background in leading and
A customer came to Flex looking for an ergonomic solution to help lift and maneuver a 40-pound Milwaukee Tool Electromagnetic drill press. The weight is often the biggest complaint among its users, causing discomfort and strain while using the tool. The FlexArm engineering team designed and created a custom solution to counterbalance the mag drill
Safety is of the utmost importance when operating heavy machinery, especially when it comes to press brakes. The large, heavy parts involved, can easily cause significant injuries if not handled properly. That’s why the team at FlexArm is committed to providing our customers with the best and safest lifting solutions.
HP |
Max RPM |
FT/LBS |
Series |
|---|---|---|---|
|
18 |
4000 |
92 |
C-20-02 / C-10-02 |
|
18 |
6000 |
61 |
C-20-02 / C-10-02 |
|
33 |
12000 |
61 |
CM-20-02 |
Auto Stand-Off – This is currently defined to be surface stand-off and not to be confused with vector stand-off in 5-axis mode. The current auto stand-off is based on a changing surface and will adjust vertically based on the angle of the “A” Axis, so there is five (5) axis taken into account during the calculations, but this is not the same as the tool vector stand-off. There is the ability to do the vector stand-off change while the machine is running manually with buttons on the screen.
Z-Reader Probe – The Z-Reader is a device for mapping the location of the surface. It can be controlled manually & programmatically. The option is NOT active while cutting & is retracted out of harm’s way. It can be triggered to verify the surface at every pierce before the cutting process starts, or it could be used to drive surface mapping of the whole part before cutting starts. It begins with initialization or zeroing of the device to the surface at the beginning of a program and then accumulates or tracks the difference from that zeroing effort.
Automatic Edge Finder – The edge finder is or can be utilized manually (Jogging Method & Screen Buttons), programmatically (M & G codes), or fully automatic routine (dedicated program). This option sets offsets & program rotation to match the orientation & location on the cutting table.
AC Unit Installed on Electrical Cabinet – The unit is mounted on the cabinet’s High Power (480v) side. It is close to the location where the drives are mounted. This option keeps the cabinet temperature stable and allows heat dissipation faster. The servo drives for all axes are the most significant contributors to heat inside the electrical cabinet.
5-Axis Renishaw Calibration – The calibration unit is a Renishaw model APCA45 with a modified spherical stylus. The device has a retractable cover and air purge to clear debris & dust during the activation process. It mounts to a swing arm controlled by a pneumatic rotary, so it is out of the way during regular operation and swings into the calibration position for calibration only.
HP |
Max RPM |
FT/LBS |
Series |
|---|---|---|---|
|
18 |
4000 |
92 |
G-20-06 / G-10-06 |
|
18 |
6000 |
61 |
G-20-06 / -10-06 |
|
40 |
4000 |
217 |
GM-20-06 / G-20-06 / G-10-06 |
|
40 |
6000 |
145 |
G-20-06 / G-20-06 / G-10-06 |
