Improving Workplace Safety with Custom Tool Balancer for Hytorc LST-2000 Torque Tool

The Problem with Heavy Tools Bolting applications often require heavy tools such as torque wrenches and impact wrenches to achieve the appropriate level of tightness for bolts. However, handling these tools can be challenging and even dangerous. Fortunately, tool balancer arms can be used to counterbalance the tool’s weight and reduce physical strain, providing added

Custom Torque Reaction Arm for Atlas Copco
Nut Runner: Improving Safety and Productivity in Industrial Applications

In industrial applications, torque reaction arms play a critical role in maintaining worker safety, improving productivity, and reducing workplace injuries. An end user came to us looking for an ergonomic solution for an Atlas Copco ETV-ST101-370-FS-F Nut Runner. The FlexArm engineering team created a custom torque reaction arm to fit their needs. This custom torque

Lightening the Load: Custom Ergonomic Solution for a Milwaukee Electromagnetic Drill Press

A customer came to Flex looking for an ergonomic solution to help lift and maneuver a 40-pound Milwaukee Tool Electromagnetic drill press. The weight is often the biggest complaint among its users, causing discomfort and strain while using the tool. The FlexArm engineering team designed and created a custom solution to counterbalance the mag drill
