The FL-Series is a highly- accurate cantilever waterjet system at a cost-effective price. Designed and constructed using the same components and technology as the top FlexJet waterjets, the FL-Series is an economical solution for a variety of applications.

FL-1004

    XYZ: 10'/ 4' / 10"
   Abrasive Cutting system
   Install, Training, 2 Year Warranty
   Complete Care+

Specifications

Linear Straightness ………………. ± .004 in./3 ft
Repeatability ………………………… ± .0025 in.
Ballbar Circularity …………………. ± .0035 in.
Acceleration ………………………….. .5G
Maximum Traverse Speed …….. 1,500 in/min
Linear Straightness ...............± .004 in./3 ft
Repeatability .......................... ± .0025 in.
Ballbar Circularity .................. ± .0035 in.
Acceleration .......................... .5G
Maximum Traverse Speed ... 1,500 in/min

Preferred abrasive of FlexJet Waterjet

Barton Logo
Quality Parts, Fast

With the fastest rapids in its class, the FL-Series offers greater efficiency for less time per part. This fast yet highly accurate cutting solution offers versatility at a value.

Built to Last

Designed and constructed using tried and true technology, the FL-Series is a dependable cutting solution built to last. The all-steel two-piece construction features a helical rack and pinion for higher accuracy and increased longevity.

Unmatched Service

Highly experienced service technicians there when you need them. From installation and training to preventative maintenance and consumable packages, we offer a level of service you can rely on.

The F-Series is a versatile waterjet offering flexibility, speed, and performance at a value. Efficient and practical, the F-Series is a reliable solution with advanced features designed to handle most cutting situations.

F-1006

    XYZ: 10'/ 6' / 12"
   Abrasive Cutting system
   Install, Training, 2 Year Warranty
   Complete Care+

Specifications

Linear Straightness ................... ± .003 in./3 ft
Repeatability .............................. ± .0015 in.
Ballbar Circularity ...................... ± .003 in.
Acceleration ................................ .7G
Maximum Traverse Speed ........ 1,600 in/min
Linear Straightness ...............± .003 in./3 ft
Repeatability .......................... ± .0015 in.
Ballbar Circularity .................. ± .003 in.
Acceleration .......................... .7G
Maximum Traverse Speed ... 1,600 in/min

Standard Options

Abrasive Cutting System
Hand Pendant
Roll Around Control

Pumps

   60 HP 90,000 PSI (Optional)

Preferred abrasive of FlexJet Waterjet

Barton Logo

5-Axis Flexibility

Patent Pending Design allowing for faster more accurate cuts

FlexJet uses a Real 5-axis not a Focal Point Design:

  • -Achieve taperless cutting with the novel 5-axis head
  • -Utilize dynamic tangential following
  • -Accurately cut difficult to reach areas
  • -Cut any angle with no limits
  • -Use any length nozzle
  • -Easy to program
  • -Easy to post
Enhanced Productivity

A practical and flexible waterjet solution for those needing a high-performance solution with 3-sided access. An advanced motion control system offers the fastest speeds and acceleration rates for faster part production and increased productivity.

Unrivaled Durability

Designed, assembled, and tested in our facility using industry-leading components, The F-Series is a reliable cutting system built for extended life. The all-steel construction is durable enough for even the most rigorous use.

Superior Service

Highly experienced service technicians are readily available when you need them. From installation and training to preventative maintenance and consumable packages, we provide you with the service you can trust.

*Additional sizes & configurations available

"When you invest in a FlexJet, you will get a high-quality, high-performance waterjet system that comes with a level of service you can rely on."

Hear what customers are saying about the Senior Software Engineer for FlexJet

“I’ve worked with Chris Ashworth for over 25 years on various waterjet cutting machine retrofits and software upgrades. When it comes to CNC software and machine capabilities, Chris is by far the most talented individual I’ve ever worked with. His knowledge of machine tools, troubleshooting and control software has been an invaluable asset for my business. His “add-ons” and modifications to our CNC controllers has increased our processing times and makes the controller very operator-friendly. I look forward to witnessing the next chapter in Chris’ career making the machines he’s dreamed of building, finally turn into a reality.”

-Doug Leaser
President
Minnesota Waterjet, Inc.

Request for More Information

Standard Features

  • Hand Pendant
  • 22″ Touch Screen Monitor
  • Omron FlexCNC Controller
  • Mobile Control Panel
  • Through Spindle Coolant
  • Auto Tool Changer
  • Flood Coolant
HP
Max RPM
FT/LBS
Series

18

4000

92

C-20-02 / C-10-02

18

6000

61

C-20-02 / C-10-02

33

12000

61

CM-20-02

Auto Stand-Off – This is currently defined to be surface stand-off and not to be confused with vector stand-off in 5-axis mode. The current auto stand-off is based on a changing surface and will adjust vertically based on the angle of the “A” Axis, so there is five (5) axis taken into account during the calculations, but this is not the same as the tool vector stand-off. There is the ability to do the vector stand-off change while the machine is running manually with buttons on the screen.

Z-Reader Probe – The Z-Reader is a device for mapping the location of the surface. It can be controlled manually & programmatically. The option is NOT active while cutting & is retracted out of harm’s way. It can be triggered to verify the surface at every pierce before the cutting process starts, or it could be used to drive surface mapping of the whole part before cutting starts. It begins with initialization or zeroing of the device to the surface at the beginning of a program and then accumulates or tracks the difference from that zeroing effort.

Automatic Edge Finder – The edge finder is or can be utilized manually (Jogging Method & Screen Buttons), programmatically (M & G codes), or fully automatic routine (dedicated program). This option sets offsets & program rotation to match the orientation & location on the cutting table.

AC Unit Installed on Electrical Cabinet – The unit is mounted on the cabinet’s High Power (480v) side. It is close to the location where the drives are mounted. This option keeps the cabinet temperature stable and allows heat dissipation faster. The servo drives for all axes are the most significant contributors to heat inside the electrical cabinet.

5-Axis Renishaw CalibrationThe calibration unit is a Renishaw model APCA45 with a modified spherical stylus. The device has a retractable cover and air purge to clear debris & dust during the activation process. It mounts to a swing arm controlled by a pneumatic rotary, so it is out of the way during regular operation and swings into the calibration position for calibration only.

HP
Max RPM
FT/LBS
Series

18

4000

92

G-20-06 / G-10-06

18

6000

61

G-20-06 / -10-06

40

4000

217

GM-20-06 / G-20-06 / G-10-06

40

6000

145

G-20-06 / G-20-06 / G-10-06
