The FlexCNC is the best priced and most flexible vertical machining center in the world. The FlexCNC vertical machining center ranges in size from 10’ to 50’ long. In addition to our standard sizes, we design and build custom machines to suit your needs.
The FlexJet is a powerful and versatile waterjet that offers exceptional flexibility, speed, durability, and superior service. With its advanced features and efficient design, this waterjet is perfect for handling a wide range of cutting situations. Whether you need to cut through tough materials or make precision cuts, the FlexJet is a reliable and practical solution with a level of service you can rely on.
With the FlexArm Tapping Arm, your shop can achieve greater profitability by empowering operators to work faster and more efficiently. The arm’s ergonomic design effortlessly articulates over the workpiece, making it simple to tap all holes in a single easy set-up. Say goodbye to time-consuming and strenuous tapping and hello to increased productivity and profitability.
The FlexBeam profile drilling center is developed for fast, accurate & economic production of steel profiles. The machine is equipped with the latest generation industrial PC-control, servodrivers & servomotors produced by OMRON.
With FlexErgo, you’ll find the perfect solution to meet any challenge, whether it’s lifting, counterbalancing, tool mounting, or more. Plus, we go the extra mile to ensure your satisfaction by designing and building customized ergonomic solutions that are tailor-made to your unique needs.
HP |
Max RPM |
FT/LBS |
Series |
---|---|---|---|
18 |
4000 |
92 |
C-20-02 / C-10-02 |
18 |
6000 |
61 |
C-20-02 / C-10-02 |
33 |
12000 |
61 |
CM-20-02 |
Auto Stand-Off – This is currently defined to be surface stand-off and not to be confused with vector stand-off in 5-axis mode. The current auto stand-off is based on a changing surface and will adjust vertically based on the angle of the “A” Axis, so there is five (5) axis taken into account during the calculations, but this is not the same as the tool vector stand-off. There is the ability to do the vector stand-off change while the machine is running manually with buttons on the screen.
Z-Reader Probe – The Z-Reader is a device for mapping the location of the surface. It can be controlled manually & programmatically. The option is NOT active while cutting & is retracted out of harm’s way. It can be triggered to verify the surface at every pierce before the cutting process starts, or it could be used to drive surface mapping of the whole part before cutting starts. It begins with initialization or zeroing of the device to the surface at the beginning of a program and then accumulates or tracks the difference from that zeroing effort.
Automatic Edge Finder – The edge finder is or can be utilized manually (Jogging Method & Screen Buttons), programmatically (M & G codes), or fully automatic routine (dedicated program). This option sets offsets & program rotation to match the orientation & location on the cutting table.
AC Unit Installed on Electrical Cabinet – The unit is mounted on the cabinet’s High Power (480v) side. It is close to the location where the drives are mounted. This option keeps the cabinet temperature stable and allows heat dissipation faster. The servo drives for all axes are the most significant contributors to heat inside the electrical cabinet.
5-Axis Renishaw Calibration – The calibration unit is a Renishaw model APCA45 with a modified spherical stylus. The device has a retractable cover and air purge to clear debris & dust during the activation process. It mounts to a swing arm controlled by a pneumatic rotary, so it is out of the way during regular operation and swings into the calibration position for calibration only.
HP |
Max RPM |
FT/LBS |
Series |
---|---|---|---|
18 |
4000 |
92 |
G-20-06 / G-10-06 |
18 |
6000 |
61 |
G-20-06 / -10-06 |
40 |
4000 |
217 |
GM-20-06 / G-20-06 / G-10-06 |
40 |
6000 |
145 |
G-20-06 / G-20-06 / G-10-06 |
